96" Rotary Rake with Category 1 & 2 3-Point Hitch — 8 Arms, Swivel Wheels

The Braber BE-GR250DR is a rotary rake built to gather cut hay into clean, consistent windrows for efficient baling. Mounting to a Category 1 & 2 3-point hitch and driven by a 540 RPM PTO, its 96" working width with 8 arms and 3 double tines per arm sweeps a wide path in a single pass — and its swivel wheels follow the ground closely for clean, thorough raking.

Matched to tractors up to 20 HP and built on a heavy-duty frame with steel guards and an adjustable swath curtain, the BE-GR250DR is a productive, durable rake well sized for smaller tractors — and its compact 52" transport width makes it easy to tow and store.

Clean, Consistent Windrows

After hay is cut and dried, it needs to be gathered into windrows before baling. The BE-GR250DR does exactly that: as the PTO spins the rotor, the 8 rotating arms — each carrying 3 double tines — sweep across the field and move the crop sideways into a clean, uniform windrow. The adjustable swath curtain shapes the windrow consistently so it feeds smoothly into the baler, while the swivel wheels let the rake follow ground contour closely for a clean rake that lifts the crop without dragging in dirt or leaving hay behind. The result is faster raking, better-formed windrows, and cleaner forage.

Features

Category 1 & 2 3-Point Hitch and 540 PTO

The BE-GR250DR mounts and powers up directly from your tractor:

• Category 1 & 2, 3-point hitch for versatile tractor compatibility
• 540 RPM PTO drive with radial pin clutch protection
• Matched to tractors up to 20 HP

8 Arms with 3 Double Tines Each

Eight rotating arms, each fitted with 3 double tines, sweep the 96" working width for fast, thorough coverage and clean windrow formation.

Swivel Wheels for Ground Following

Swivel wheels let the rake follow the contour of the ground closely, keeping the tines at a consistent working height for a clean rake across uneven fields.

Adjustable Swath Curtain

An adjustable swath curtain shapes the crop into a clean, consistent windrow, helping it feed smoothly into the baler.

Manual Height Adjustment

Manual height adjustment sets the tine height precisely for the conditions, for clean raking that lifts the crop without dragging the ground.

Heavy-Duty Frame with Steel Guards

A heavy-duty frame and protective steel guards give the BE-GR250DR the durability for dependable performance season after season.

Compact Transport Width

A compact 52" transport width makes the BE-GR250DR easy to tow between fields and along narrow lanes, and simple to store.

Built for Haymaking and Forage

With a wide working width and clean windrow formation, the BE-GR250DR is suited for:

• Raking cut hay into windrows for baling
• Gathering forage crops cleanly and efficiently
• Working hay fields with smaller tractors
• Forming consistent windrows for smooth baler feeding

Warranty

The BE-GR250DR is backed by Braber Equipment's limited warranty — contact your dealer for current warranty terms and coverage details.

Product Specifications

• Mounting: Category 1 & 2, 3-Point Hitch
• Drive: 540 RPM PTO with Radial Pin Clutch
• Power Requirement: Up to 20 HP Tractor
• Working Width: 96"
• Arms: 8
• Tines: 3 Double Tines per Arm
• Wheels: Swivel
• Height Adjustment: Manual
• Swath Curtain: Adjustable
• Frame: Heavy-Duty with Steel Guards
• Transport Width: 52"
• Weight: 616 lbs
• SKU: BE-GR250DR
• Brand: Braber Equipment

Note: Performance varies with crop type, moisture, and field conditions, as well as available tractor horsepower. Product may vary slightly from images shown. Specifications are subject to change without notice — confirm details with your dealer prior to purchase.

Efficient Windrowing — Built by Braber

The Braber BE-GR250DR combines a Category 1 & 2 3-point hitch, 540 PTO drive, 8 arms with double tines, swivel ground-following wheels, and an adjustable swath curtain into one productive 96" rotary rake. For gathering hay into clean windrows quickly, the BE-GR250DR covers the field and forms the row.

BE-GR250DR — 96" Rotary Rake with Category 1 & 2 3-Point Hitch and 8 Arms.
