1" Straight Clevis — Screw-Pin Farm Clevis, 17,000 lb Working Load Limit

The Braber 64.350.001 is a heavy-duty screw-pin, shackle-type farm clevis for connecting multiple hitches, chains, drawbars, and crawler-tractor implements. Rated for a 17,000 lb working load limit, it delivers dependable strength for heavy-duty towing and hitching, with a 1-1/8" screw pin and a 1-11/16" clevis opening for versatile connections.

Strong, Versatile Hitching Hardware

A straight clevis is one of the most useful pieces of hardware on the farm — a rugged U-shaped shackle with a removable screw pin that links drawbars, chains, and implements for towing and pulling. The 64.350.001's screw-pin design threads in and out for quick, secure connections, its 1" body and 3-3/4" usable length give reliable fitment, and a powder-painted finish protects against corrosion. Built for the demands of heavy ag work, it stands up to a 17,000 lb working load.

Features

• Screw-pin, shackle-type farm clevis for connecting multiple hitches and crawler-tractor implements
• 17,000 lb working load limit for heavy-duty towing and hitching
• 1-1/8" screw pin with a 1-11/16" clevis opening for versatile connections
• 1" body diameter with a 3-3/4" usable length for reliable fitment
• Powder-painted finish for lasting corrosion resistance
• Sturdy 4.95 lb build

Important Usage Note

This is farm hardware — not for lifting. Do not use the clevis for overhead or personnel lifting, and never exceed the rated working load limit.

Warranty

This clevis is backed by Braber Equipment's limited warranty — contact your dealer for current warranty terms and coverage details.

Product Specifications

• Type: Straight Farm Clevis (Screw-Pin, Shackle-Type)
• Working Load Limit: 17,000 lbs
• Screw Pin: 1-1/8"
• Clevis Opening: 1-11/16"
• Body Diameter: 1"
• Usable Length: 3-3/4"
• Finish: Powder-Painted
• Weight: 4.95 lbs
• SKU: 64.350.001
• Brand: Braber Equipment

Note: Farm hardware — not for lifting. Do not exceed the working load limit. Product may vary slightly from images shown. Specifications are subject to change without notice — confirm details with your dealer prior to purchase.

64.350.001 — 1" Straight Screw-Pin Farm Clevis, 17,000 lb Working Load Limit.
